Official Characteristics (from Borsan / Nexans data)
- Conductors: 5 × 10 mm² stranded copper (Class 2)
- Insulation: XLPE; Filler and Outer Sheath: PVC, flame‑retardant (IEC 60332‑1, XP C 32‑321), UV-resistant in black jacket .
- Voltage Rating: 0.6/1 kV; test voltage 4 kVAC .
- Operating Temperatures: continuous up to 85 °C; short‑circuit up to 250 °C; ambient −10 °C to +60 °C; installation ≥ 5 °C .
- Current Capacity: ~71 A in open air; ~79 A when buried .
- Diameter / Weight: ~20 mm outer diameter; ~725 kg per km .
- Bending radius: factor 6 × D (~120 mm) in laying operations; ~204 mm static minimum radius .
- Standards: XP C 32‑321, flame classification C2 according to NF C 32‑070, IEC 60332‑1 test passed
